Shield Stain Medium Mix

Shield Stain Medium mix is a high performance gas for used for the welding of stainless steel and duplex

He / Ar / O₂

Like Shieldpro, Shield Stain mixtures have the addition of predominantly helium, hydrogen or nitrogen, which enables them to achieve higher performance in the areas of welding speed, penetration, profile, surface appearance, metallurgical benefits etc. This improves the two major areas of concern in a welding process - quality and economics

Uses

  • Ideal for MIG welding of stainless steels of all thicknesses
  • Good deposition rates, weld profile and smooth surface appearance
Product Summary

Gas composition

  • Helium
  • Argon
  • Oxygen

Compressed gas sizes

UN number: 1956

Download safety data sheet

Scroll

Size Product code Volume / m³ Weight (full) / kg Pressure / kPa Outlet connection Availability
G 9.9 72.3 20,000 Type 10 NZ wide
Additional Details

Physical & chemical properties

Appearance Odour Flammability
AppearanceColourless gas OdourOdourless FlammabilityNon flammable

Hazard class

2.2

Hazard symbol (GHS)

  • Non-flammable non-toxic gas 2.2
